Gaussian Process Port-Hamiltonian Systems

Gaussian Process Port-Hamiltonian Systems (GP-PHS) combine Gaussian Processes with the structure of Port-Hamiltonian systems to learn continuous-time dynamics while preserving physical properties such as energy balance and passivity. GP-PHS places a Gaussian Process prior on the Hamiltonian, yielding probabilistic dynamics with uncertainty quantification.

For further details, see the original paper: Gaussian Process Port-Hamiltonian Systems: Bayesian Learning with Physics Prior

Tutorials

Data Preparation

Modules: neuromancer.psl.gp_smoother | neuromancer.dataset

The data preparation pipeline transforms raw state observations into the format required by GPPHSNode for training. It has two stages:

GP Smoothing: fit a GP to noisy state measurements to obtain smoothed states, derivative estimates, and derivative variances.
DataLoader construction: split the smoothed arrays into train/dev/test sets and wrap them in NeuroMANCER-compatible DataLoaders.

The two stages are intentionally separate so you can substitute your own derivative estimates if you already have them, bypassing the GP smoother.

gp_smooth

Module: neuromancer.psl.gp_smoother

gp_smooth(
    t:         np.ndarray,
    x:         np.ndarray,
    n_iter:    int = 100,
    lr:        float = 0.1,
    noise_var: float = 0.01,
) -> Tuple[np.ndarray, np.ndarray, np.ndarray]

Fits an independent scalar RBF GP to each state dimension using the observed timestamps t and noisy state measurements x. Returns smoothed states, derivative means, and derivative variances.

For each state dimension, the GP is:

xₐ(t) ~ GP(0, k_rbf(t, t'))

Parameters

Parameter	Type	Description
`t`	`np.ndarray (T,)`	Timestamps
`x`	`np.ndarray (T, nx)`	Noisy state observations
`n_iter`	`int`	Number of Adam optimization steps for hyperparameter fitting. Default `100`.
`lr`	`float`	Learning rate for hyperparameter optimization. Default `0.1`.
`noise_var`	`float`	Initial observation noise variance. Default `0.01`.

Returns

Output	Shape	Description
`x_smooth`	`(T, nx)`	GP posterior mean — smoothed state estimates
`x_dot_smooth`	`(T, nx)`	Derivative posterior mean at each observation time
`x_dot_var`	`(T, nx)`	Derivative posterior variance — used as `Δ` diagonal in the GP-PHS NLML

All outputs are NumPy arrays.

Usage

from neuromancer.psl import gp_smoother

x_smooth, xdot_smooth, xdot_var = gp_smoother.gp_smooth(t, x_noisy)

get_gpphs_dataloaders

Module: neuromancer.dataset

get_gpphs_dataloaders(
    x:           np.ndarray,
    x_dot:       np.ndarray,
    u:           np.ndarray = None,
    x_dot_var:   np.ndarray = None,
    split_ratio: List[float] = None,
    batch_size:  int = 32,
    num_workers: int = 0,
) -> Tuple[DataLoader, DataLoader, DataLoader]

Builds NeuroMANCER-compatible DataLoaders from pre-computed smoothed state and derivative arrays. Validates and reshapes inputs, constructs the data dictionary, then delegates to get_static_dataloaders for splitting and wrapping.

Parameters

Parameter	Type	Description
`x`	`np.ndarray (T, nx)`	Smoothed state observations
`x_dot`	`np.ndarray (T, nx)`	Derivative estimates
`u`	`np.ndarray (T, nu)`	Control inputs. Optional — pass `None` for uncontrolled systems.
`x_dot_var`	`np.ndarray (T, nx)`	Derivative variances from `gp_smooth`. Optional but recommended.
`split_ratio`	`List[float]`	Train/dev/test split as percentages summing to 100, e.g. `[75.0, 15.0, 10.0]`.
`batch_size`	`int`	Batch size for all three loaders. Default `32`. For GP-PHS, setting this to the full dataset size is recommended since the NLML benefits from seeing all data per step.
`num_workers`	`int`	Number of DataLoader worker processes. Default `0`.

Returns

(train_loader, dev_loader, test_loader) — three NeuroMANCER DataLoader instances. Each batch contains the keys 'X', 'Xdot', and optionally 'U' and 'Xdot_var', matching the input signature of GPPHSNode.forward.

Validation

Check	Behavior
`x` and `x_dot` shapes do not match	Raises `AssertionError`
`u` row count does not match `x`	Raises `AssertionError`
`x_dot_var` shape does not match `x_dot`	Raises `AssertionError`

Usage

from neuromancer import dataset

train_loader, dev_loader, test_loader = dataset.get_gpphs_dataloaders(
    x=x_smooth,
    x_dot=xdot_smooth,
    u=u_i,
    x_dot_var=xdot_var_np,
    split_ratio=[75.0, 15.0, 10.0],
    batch_size=N_POINTS,
)

1D inputs are reshaped automatically. If x, x_dot, u, or x_dot_var are passed as (T,) arrays, they are reshaped to (T, 1) automatically.

PHSMatrices

Module: neuromancer.dynamics.gp_phs | Base class: torch.nn.Module

PHSMatrices encodes the structural matrices of a Port-Hamiltonian System. J (skew-symmetric interconnection), R (diagonal dissipation), and G (input coupling).

Constructor

PHSMatrices(
    nx: int,
    nu: int,
    J_upper: Dict[Tuple[int, int], Callable],
    R_diag:  Dict[int, Callable],
    G_full:  Dict[Tuple[int, int], Callable],
)

Parameters

Parameter	Type	Description
`nx`	`int`	State dimension. Determines the size of J and R as `(nx, nx)` and G as `(nx, nu)`.
`nu`	`int`	Control input dimension. Determines the number of columns in G.
`J_upper`	`Dict[Tuple[int,int], Callable]`	Upper-triangle entries of J. Keys are index pairs `(i, j)` with `i < j`. Each value is a callable `f(x) -> Tensor` of shape `(batch,)`.
`R_diag`	`Dict[int, Callable]`	Diagonal entries of R. Keys are row indices `i`. Each value is a callable `f(x) -> Tensor` of shape `(batch,)`.
`G_full`	`Dict[Tuple[int,int], Callable]`	Arbitrary entries of G. Keys are index pairs `(i, j)` where `i` indexes a state row and `j` indexes a control column. Each value is a callable `f(x) -> Tensor` of shape `(batch,)`.

Structural Constraints

Skew-symmetry of J. You only define the strictly upper triangle (i < j). The constructor rejects any key that violates this. The lower triangle is filled at evaluation time as J[j, i] = -J[i, j]. The diagonal is always zero.

Diagonal dissipation matrix R. Each diagonal entry is supplied as a callable f(x) -> Tensor. During construction, GP-PHS automatically detects whether each callable is constant or state dependent using automatic differentiation.

Constant entries are automatically assigned a differentiable positivity transform (implemented using the softplus function), guaranteeing that the corresponding diagonal entry remains nonnegative throughout optimization.
State-dependent entries are evaluated exactly as provided. Since positive semi-definiteness cannot, in general, be guaranteed for an arbitrary state-dependent function, these entries are validated after training.

G is unconstrained. No structural constraint is imposed.

Note: Any unspecified entry is assumed to be zero.

Parameter Auto-Detection

GP-PHS automatically detects whether each diagonal entry of R is constant or state dependent by checking whether the supplied callable depends on the state variable x using PyTorch automatic differentiation.

For constant entries, positivity is enforced automatically through the associated learnable parameter.

Detection supports:

Parameters captured through Python closures
Parameters stored inside nn.Module objects
Parameters referenced from notebook scope
Parameters referenced from module-level globals

For example:

b = variable(
    torch.tensor([1.0], requires_grad=True),
    display_name='b'
)

R_diag = {
    1: lambda x: b.value * torch.ones(x.shape[0])
}

The callable above is detected as constant, since it does not depend on the values of x.

Methods

forward(x: Tensor) -> Tuple[Tensor, Tensor, Tensor]

Evaluates all three matrices at the current state batch. Calls get_J, get_R, and get_G in sequence.

Argument	Shape	Description
`x`	`(batch, nx)`	State batch

Returns: (J, R, G) where each is a Tensor:

Output	Shape	Constraint
`J`	`(batch, nx, nx)`	Skew-symmetric
`R`	`(batch, nx, nx)`	Diagonal (PSD guaranteed for constant entries)
`G`	`(batch, nx, nu)`	Unconstrained

Validation and Warnings

Check	Behavior
`J_upper` key `(i,j)` has `i >= j` or is out of range	Raises `ValueError`
`R_diag` key `i` is out of `[0, nx)`	Raises `ValueError`
`G_full` key `(i,j)` is out of range	Raises `ValueError`
`R_diag` is missing one or more diagonal indices	Issues `UserWarning` (R will be degenerate)
State-dependent diagonal entry of `R` becomes negative	Raises `ValueError` after training if any sampled state produces a negative diagonal entry.

Usage Example

This example models a simple mass-spring-damper system with two states (NX=2, position and momentum) and one control input (NU=1). The damping coefficient b is a learnable parameter declared using variable.

import torch
from neuromancer.constraint import variable
import neuromancer.dynamics.gp_phs as gp_phs

b = variable(
    torch.tensor([1.0], requires_grad=True),
    display_name='b'
)

phs = gp_phs.PHSMatrices(
    nx=NX, nu=NU,
    J_upper={
        (0, 1): lambda x: torch.ones(x.shape[0])
    },
    R_diag={
        0: lambda x: torch.zeros(x.shape[0]),
        1: lambda x: b.value * torch.ones(x.shape[0])
    },
    G_full={
        (0, 0): lambda x: torch.zeros(x.shape[0]),
        (1, 0): lambda x: torch.ones(x.shape[0])
    },
)

The assembled matrices at any state batch x will have the following structure:

J = [[ 0,  1],   R = [[0,        0  ],   G = [[0],
     [-1,  0]]        [0, b.value  ]]          [1]]

Parameter Utilities

param_table(
    param_map: Dict[str, Tuple[Any, Optional[float]]]
) -> pd.DataFrame

Prints a comparison table of learned versus reference parameter values.

For each parameter:

learned = param.value.detach().item()

Relative error is computed as:

100 * abs(learned - true_val) / (abs(true_val) + 1e-6)

Rows with true_val=None are excluded from the mean and median error statistics.

Usage

df = gp_phs.param_table({
    'b': (b, B_TRUE),
})

Example output:

Parameter  True  Learned  Rel. Error %
b          0.50    0.503          0.60

Mean relative error:   0.60%
Median relative error: 0.60%

PHSKernel

Module: neuromancer.dynamics.gp_phs | Base class: gpytorch.kernels.Kernel

PHSKernel is a structured, non-stationary GP kernel that encodes Port-Hamiltonian dynamics directly into the covariance function. It enforces the (J-R)∇H part of the PHS equation at the kernel level by sandwiching the Hessian of a base RBF kernel between the (J-R) matrices evaluated at the input points:

k_phs(x, x') = σ²f · (J(x) - R(x)) · H_rbf(x, x') · (J(x') - R(x'))ᵀ

where H_rbf is the matrix of mixed second-order partial derivatives of a squared exponential kernel with diagonal lengthscale matrix Λ. This construction guarantees that samples drawn from the GP are consistent with Hamiltonian structure.

PHSKernel is not instantiated directly by the user. It is constructed internally by GPPHSNode, which wires it together with the likelihood and the GP model.

Constructor

PHSKernel(
    phs_matrices: PHSMatrices,
    nx: int,
    **kwargs,
)

Parameters

Parameter	Type	Description
`phs_matrices`	`PHSMatrices`	The structural matrix definition from Step 2. Provides `get_J(x)` and `get_R(x)` at forward time. Note that `G` does not appear in the kernel — input coupling is applied externally.
`nx`	`int`	State dimension. Determines the size of the output kernel block and the length of the learnable lengthscale vector.
`**kwargs`		Passed to the GPyTorch `Kernel` base class (e.g. `active_dims`).

Learnable Parameters

These are registered automatically and included in the optimizer alongside the physical parameters declared in PHSMatrices.

Parameter	Shape	Constraint	Description
`raw_lengthscale`	`(nx,)`	Softplus, strictly positive	Diagonal of the lengthscale matrix Λ. One lengthscale per state dimension.
`raw_signal_var`	`()`	Softplus, strictly positive	Overall signal variance σ²f. Scales the kernel amplitude.

Methods

forward(x1: Tensor, x2: Tensor, **params) -> DenseLinearOperator

Computes the full PHS kernel matrix between two state batches. The output is a DenseLinearOperator of shape (N·nx, M·nx), where each (nx, nx) block corresponds to a pair of input points and encodes the covariance between all state derivative dimensions at those points.

Parameters

Argument	Shape	Description
`x1`	`(N, nx)`	First batch of states
`x2`	`(M, nx)`	Second batch of states

_rbf_and_hessian(x1, x2)

_rbf_and_hessian(
    x1: Tensor,
    x2: Tensor
) -> Tuple[Tensor, Tensor]

The Hessian is computed analytically. There is no finite-difference or autograd approximation. The mixed partial ∂²k/∂xᵢ∂x'ⱼ is derived in closed form from the RBF kernel and computed fully vectorized over the batch, which keeps training efficient.

Returns

Output	Shape	Description
`k_rbf`	`(N, M)`	Scalar RBF kernel values
`H`	`(N, M, nx, nx)`	Mixed second-order partial derivatives `∂²k/∂xᵢ∂x'ⱼ`

Numerical Stability

If R has zero diagonal entries—as is common when some state dimensions are conservative—the matrix (J-R) becomes rank-deficient and the kernel matrix K can become singular. To prevent Cholesky failures during GP training, forward adds a scaled jitter term to the diagonal:

jitter = K_out.diagonal().mean() * 1e-4
K_out = K_out + torch.eye(...) * jitter

This keeps K positive-definite without meaningfully distorting the kernel signal.

PHSMeanFunction

Module: neuromancer.dynamics.gp_phs | Base class: gpytorch.means.Mean

PHSMeanFunction defines the prior mean of the GP-PHS model. It encodes the contribution of control inputs to the state derivatives through the input coupling matrix G:

m(x, u) = G(x) · u

PHSMeanFunction is constructed and managed internally by GPPHSModel.

Constructor

PHSMeanFunction(
    phs_matrices: PHSMatrices,
    nx: int,
    nu: int,
)

Parameters

Parameter	Type	Description
`phs_matrices`	`PHSMatrices`	Provides `get_G(x)` at forward time.
`nx`	`int`	State dimension.
`nu`	`int`	Control input dimension.

Methods

forward(x: Tensor, u: Tensor) -> Tensor

Computes the prior mean vector for a batch of state-input pairs.

Parameters

Argument	Shape	Description
`x`	`(N, nx)`	State batch
`u`	`(N, nu)`	Control input batch

Returns

Returns a Tensor of shape (N·nx,)—the flattened mean vector, matching the layout of the (N·nx, M·nx) kernel matrix produced by PHSKernel.

The computation is a batched matrix-vector product. For each data point n:

mean[n] = G(xₙ) · uₙ    # (nx,)

The results are stacked to (N, nx) and then flattened to (N·nx,).

GPPHSModel

Module: neuromancer.dynamics.gp_phs | Base class: torch.nn.Module

GPPHSModel assembles the prior mean and kernel into a single GPyTorch-compatible model that returns a MultivariateNormal distribution over state derivatives:

ẋ ~ GP(G(x)u, k_phs(x, x'))

The mean function encodes the known control contribution G(x)·u, and the kernel encodes the PHS structure of the unknown Hamiltonian gradient (J-R)∇H. Together they define a structured prior that constrains the GP to produce dynamics consistent with PHS theory.

Why Not `ExactGP`

GPyTorch’s ExactGP assumes N scalar inputs map to N scalar outputs. The PHS model has N state inputs mapping to N·nx vector outputs—one derivative per state dimension per data point. This shape conflicts with ExactGP’s internal noise handling. GPPHSModel therefore inherits from nn.Module directly, and the NLML is computed externally in GPPHSLoss.

Constructor

GPPHSModel(
    phs_matrices: PHSMatrices,
    nx: int,
    nu: int,
)

Parameters

Parameter	Type	Description
`phs_matrices`	`PHSMatrices`	Passed to both `PHSMeanFunction` and `PHSKernel`.
`nx`	`int`	State dimension.
`nu`	`int`	Control input dimension.

Methods

forward(x: Tensor, u: Tensor) -> MultivariateNormal

Evaluates the GP prior at the given state-input batch.

Parameters

Argument	Shape	Description
`x`	`(N, nx)`	State batch
`u`	`(N, nu)`	Control input batch

Returns

Returns a gpytorch.distributions.MultivariateNormal with:

Field	Shape	Description
`mean`	`(N·nx,)`	Prior mean `G(x)·u`, flattened
`covariance_matrix`	`(N·nx, N·nx)`	PHS kernel matrix `k_phs(x, x')`

Usage

GPPHSModel is constructed and managed internally by GPPHSNode. In normal usage you do not instantiate it directly.

If you need direct access to the GP model after training—for example to inspect the learned kernel or call the posterior—it is available through:

gpphs_node.callable.gp_model              # GPPHSModel instance
gpphs_node.callable.gp_model.covar_module # PHSKernel
gpphs_node.callable.gp_model.mean_module  # PHSMeanFunction

GPPosterior

Module: neuromancer.dynamics.gp_phs | Base class: torch.nn.Module

GPPosterior computes the Bayesian posterior over the Hamiltonian H(x*) at test points, conditioned on the observed state derivatives from training. It is the bridge between training and inference: once GPPHSNode has been trained, GPPosterior takes the learned parameters and produces a distribution over H that can be sampled, visualized, and used to build a callable H*.

The posterior is derived from the joint distribution over state derivatives ẋ and Hamiltonian values H(x*):

[ẋ      ]       [K_phs           k_ẋH(X, x*) ]
[H(x*)] ~ N(0,  [k_ẋH(X,x*)ᵀ   k_HH(x*, x*) ])

Conditioning on the observed ẋ (after subtracting the known G·u contribution) gives the posterior mean and covariance over H:

μ_H = k_ẋH(X, x*)ᵀ · (K_phs + Δ)⁻¹ · (ẋ - G·u)
Σ_H = k_HH(x*, x*) - k_ẋH(X, x*)ᵀ · (K_phs + Δ)⁻¹ · k_ẋH(X, x*)

where Δ is the derivative noise matrix supplied by the GP smoother.

GPPosterior is obtained by calling posterior() on a trained GPPHSNode. You do not instantiate it directly.

Constructor

GPPosterior(
    model:        GPPHSModel,
    likelihood:   GaussianLikelihood,
    phs_matrices: PHSMatrices,
    lengthscale:  Tensor,
    signal_var:   Tensor,
    noise_var:    Tensor,
)

Parameters

Parameter	Type	Description
`model`	`GPPHSModel`	The trained GP model. Set to eval mode on construction.
`likelihood`	`GaussianLikelihood`	The trained likelihood. Set to eval mode on construction.
`phs_matrices`	`PHSMatrices`	The trained structural matrices. Provides `get_J`, `get_R`, `get_G` at inference time.
`lengthscale`	`Tensor (nx,)`	Learned lengthscale vector, detached from the computation graph.
`signal_var`	`Tensor`	Learned signal variance σ²f, detached.
`noise_var`	`Tensor`	Learned noise variance, detached.

All three tensor arguments are registered as buffers, not parameters. No gradients are computed inside GPPosterior.

Methods

predict(
    smoothed:   List[np.ndarray],
    us:         List[np.ndarray],
    xdots:      List[np.ndarray],
    xdot_vars:  List[np.ndarray],
    test_x:     Tensor = None,
    n_samples:  int = 20,
) -> Tuple[Tensor, Tensor, Tensor]

The primary interface for computing the Hamiltonian posterior. Accepts lists of NumPy arrays—one per trajectory—concatenates them, converts to tensors, and calls forward. This matches the natural output format of the GP smoother, where each trajectory is stored separately.

Parameters

Argument	Type	Description
`smoothed`	`List[np.ndarray]`	Smoothed states, one array of shape `(N_i, nx)` per trajectory
`us`	`List[np.ndarray]`	Control inputs, one array of shape `(N_i, nu)` per trajectory
`xdots`	`List[np.ndarray]`	Smoothed derivatives, one array of shape `(N_i, nx)` per trajectory
`xdot_vars`	`List[np.ndarray]`	Derivative variances from the GP smoother, one array of shape `(N_i, nx)` per trajectory
`test_x`	`Tensor`	States at which to evaluate `H`. Defaults to the concatenated training states if `None`.
`n_samples`	`int`	Number of posterior samples to draw. Default `50`.

Returns

Returns (H_mean, H_var, H_samples):

Output	Shape	Description
`H_mean`	`(M,)`	Posterior mean of `H` at test points.
`H_var`	`(M,)`	Posterior variance of `H` at test points, clamped to non-negative.
`H_samples`	`(n_samples, M)`	Samples drawn from the posterior over `H`.

forward(train_x, train_u, train_xdot, test_x, n_samples, xdot_var)

forward(
    train_x:    Tensor,
    train_u:    Tensor,
    train_xdot: Tensor,
    test_x:     Tensor,
    n_samples:  int = 20,
    xdot_var:   Tensor = None,
) -> Tuple[Tensor, Tensor, Tensor]

Core posterior computation. Accepts tensors directly. In most cases you should use predict instead, which handles list-of-trajectory inputs and NumPy conversion.

Returns

The computation proceeds as follows:

Build k_ẋH(X, x*) — cross-kernel between training derivatives and test Hamiltonian values.
Build k_HH(x*, x*) — scalar RBF kernel at test points.
Build K_phs + Δ — training kernel matrix plus derivative noise.
Subtract the prior mean G(x)·u from train_xdot to isolate the Hamiltonian residual.
Solve for
```
α = (K_phs + Δ)⁻¹ · (ẋ - G·u)
```
via Cholesky decomposition.
Compute posterior mean μ_H and covariance Σ_H.
Draw samples using eigendecomposition of Σ_H to handle near-indefinite covariances numerically.

The return signature is the same as predict: (H_mean, H_var, H_samples).

Usage

# After training
posterior = gpphs_node.callable.posterior()

# Compute Hamiltonian posterior
H_mean, H_var, H_samples = posterior.predict(
    smoothed=[x_smooth],
    us=[u_i],
    xdots=[xdot_smooth],
    xdot_vars=[xdot_var_np],
    n_samples=50,
)

Each argument is a list with one array per trajectory. For a single trajectory, wrap the array in a list as shown above.

For multiple trajectories, pass one array per trajectory and they will be concatenated automatically:

H_mean, H_var, H_samples = posterior.predict(
    smoothed=[x_smooth_1, x_smooth_2],
    us=[u_1, u_2],
    xdots=[xdot_1, xdot_2],
    xdot_vars=[xdot_var_1, xdot_var_2],
    n_samples=50,
)

Notes

Hamiltonians are identifiable only up to an additive constant. The GP models ∇H, not H directly. Two Hamiltonians that differ by a constant produce identical dynamics. The posterior mean is therefore aligned to the training data, but its absolute value has no physical meaning on its own. Comparisons against a true Hamiltonian should account for this offset.

No gradients are computed. The entire forward method runs inside torch.no_grad(). GPPosterior is an inference-only object.

GPPHSNode

Module: neuromancer.dynamics.gp_phs | Base class: torch.nn.Module

GPPHSNode is the NeuroMANCER-compatible wrapper that connects the GP-PHS model to the Problem / Trainer training loop. It owns the likelihood, the GP model, and the PHS matrices, and exposes a single forward method that computes the Negative Log Marginal Likelihood (NLML) used as the training objective.

All learnable components—kernel hyperparameters, likelihood noise, and physical parameters from PHSMatrices—are registered as nn.Module children and are therefore captured automatically by problem.parameters() and the optimizer. You do not need to collect or pass them manually.

Constructor

GPPHSNode(
    phs_matrices: PHSMatrices,
    nx: int,
    nu: int,
)

Parameters

Parameter	Type	Description
`phs_matrices`	`PHSMatrices`	The structural matrix definition from Step 2. Owned by this module for its lifetime.
`nx`	`int`	State dimension.
`nu`	`int`	Control input dimension.

Owned Parameters

All of the following are registered as child modules and included in problem.parameters() automatically.

Parameter	Shape	Registered in	Description
Physical params (e.g. `b`)	scalar per parameter	`PHSMatrices`	Declared via `positive_param` or `nonneg_param` in Step 2.
`raw_lengthscale`	`(nx,)`	`PHSKernel`	One lengthscale per state dimension.
`raw_signal_var`	`(1,)`	`PHSKernel`	Overall kernel signal variance σ²f.
`raw_noise`	`(1,)`	`GaussianLikelihood`	Observation noise variance, initialized to `1e-3` with a lower bound of `1e-4`.

For a model with P physical parameters and state dimension nx, the total number of parameter tensors seen by the optimizer is P + nx + 2.

Methods

forward(
    X:        Tensor,
    U:        Tensor,
    Xdot:     Tensor,
    Xdot_var: Tensor = None,
) -> Tensor

Computes and returns the scalar NLML for the current batch using GPPHSLoss. This is stored under the key 'nlml' in the NeuroMANCER problem dictionary and is what the optimizer minimizes.

On the first forward pass, raw_signal_var is initialized from the empirical variance of Xdot. This prevents the optimizer from starting in a near-zero basin where the GP ignores dynamics structure entirely. This initialization happens once and does not repeat on subsequent forward calls.

Parameters

Argument	Shape	Description
`X`	`(N, nx)`	State batch.
`U`	`(N, nu)`	Control input batch.
`Xdot`	`(N, nx)`	Observed state derivatives, typically the smoothed output from the GP smoother.
`Xdot_var`	`(N, nx)`	Per-observation derivative variances from the GP smoother. Optional but recommended.

Returns

Returns a scalar Tensor containing the NLML value for the current batch.

posterior()

posterior() -> GPPosterior

Constructs a GPPosterior object using the currently learned model parameters. Call this after training to move into the Hamiltonian posterior computation (Step 5). The returned object captures a snapshot of the learned lengthscale, signal_var, and noise_var at the time of the call.

Returns

Returns a GPPosterior instance.

Usage

import neuromancer.dynamics.gp_phs as gp_phs
from neuromancer.system import Node
from neuromancer.constraint import variable
from neuromancer.loss import PenaltyLoss
from neuromancer.problem import Problem

# build node, loss, and problem
gpphs_module = gp_phs.GPPHSNode(phs, NX, NU)
gpphs_node = Node(
    gpphs_module,
    ['X', 'U', 'Xdot', 'Xdot_var'],
    ['nlml'],
    name='gp_phs',
)

nlml = variable('nlml')
nlml_loss = nlml.minimize()
nlml_loss.name = 'nlml_loss'

loss = PenaltyLoss([nlml_loss], [])
problem = Problem([gpphs_node], loss)

print(f'{len(list(problem.parameters()))} total parameter tensors')

After training, move to the Hamiltonian posterior:

posterior = gpphs_node.callable.posterior()

Note the .callable accessor—NeuroMANCER’s Node wraps the module, so the GPPHSNode instance is accessed through gpphs_node.callable, not gpphs_node directly.

Notes

Do not call ``posterior()`` before training. The method will succeed technically since it only reads the current parameter values, but those values will be at their initialization point and the resulting posterior will not reflect learned dynamics.

GPPHSLoss

Module: neuromancer.loss | Base class: torch.nn.Module

GPPHSLoss computes the Negative Log Marginal Likelihood (NLML) for the GP-PHS model via direct Cholesky decomposition:

NLML = 0.5 · rᵀ(K + Δ)⁻¹r + log|L| + 0.5 · N·nx · log(2π)

where r = ẋ - G(x)·u is the residual after subtracting the prior mean, K is the PHS kernel matrix, Δ is the derivative noise matrix from the GP smoother, and L is the Cholesky factor of K + Δ.

GPyTorch’s ExactMarginalLogLikelihood cannot be used here because ExactGP assumes N inputs mapping to N scalar outputs. The PHS model has N inputs mapping to N·nx outputs, so the noise shape conflicts. GPPHSLoss handles this directly.

GPPHSLoss is constructed and managed internally by GPPHSNode. You do not instantiate it directly.

Constructor

GPPHSLoss(
    model: GPPHSModel,
    likelihood: GaussianLikelihood,
)

Methods

forward(
    x:        Tensor,
    u:        Tensor,
    xdot:     Tensor,
    xdot_var: Tensor = None,
) -> Tensor

Parameters

Argument	Shape	Description
`x`	`(N, nx)`	State batch.
`u`	`(N, nu)`	Control input batch.
`xdot`	`(N, nx)`	Observed state derivatives.
`xdot_var`	`(N, nx)`	Per-point derivative variances from `gp_smooth`. If `None`, falls back to `likelihood.noise · I`.

Returns

Returns a scalar NLML. Minimizing this maximizes the marginal likelihood over the kernel hyperparameters and physical parameters simultaneously.

Notes

A small scaled jitter is added to the diagonal before the Cholesky decomposition for floating-point stability. The PHS kernel is PSD by construction, so this does not affect the solution meaningfully.

HamiltonianApproximator

Module: neuromancer.modules.hamiltonian_approximator | Base class: torch.nn.Module

HamiltonianApproximator fits a callable H*(x) to a set of sampled Hamiltonian values from GPPosterior and exposes both evaluation and gradient computation at arbitrary query points. Once fitted, it can be used to compute the full PHS dynamics:

ẋ = (J(x) - R(x)) · ∇H*(x) + G(x) · u

In practice you build one approximator per posterior sample, forming an ensemble that carries uncertainty from the Hamiltonian posterior through to derivative and trajectory predictions.

Two methods are available:

Method	Description	Gradient
`'gp'`	GP with SE kernel. Uses the learned lengthscales and signal variance from the trained GP-PHS model.	Analytic
`'spline'`	Thin-plate spline via `scipy`. No hyperparameters required.	Autograd

'gp' is recommended when lengthscale and signal variance are available from the posterior, since the kernel structure is consistent with the training model.

Constructor

HamiltonianApproximator(
    method: str = 'spline',
    lengthscale: Tensor = None,
    signal_var: Tensor = None,
    noise: float = 0.0,
)

Parameters

Parameter	Type	Description
`method`	`str`	`'gp'` or `'spline'`. Default `'spline'`.
`lengthscale`	`Tensor (nx,)`	Learned lengthscale vector from the posterior. Required for `method='gp'`.
`signal_var`	`Tensor`	Learned signal variance from the posterior. Required for `method='gp'`.
`noise`	`float`	Nugget added to the GP diagonal for numerical stability. Default `0.0`.

Methods

fit(x: Tensor, H_vals: Tensor) -> HamiltonianApproximator

Fits the approximator to a set of state-Hamiltonian pairs. Returns self so it can be chained directly with the constructor.

Parameters

Argument	Shape	Description
`x`	`(M, nx)`	State points.
`H_vals`	`(M,)`	Sampled Hamiltonian values at those states, typically one row from `H_samples`.

Returns

Returns self so the method can be chained directly with the constructor.

Usage

After computing the Hamiltonian posterior in Step 5, build one approximator per sample using the learned lengthscales and signal variance from the posterior:

x_smooth_t = torch.tensor(x_smooth, dtype=torch.float32)

ensemble = [
    hamiltonian_approximator.HamiltonianApproximator(
        method='gp',
        lengthscale=posterior.lengthscale,
        signal_var=posterior.signal_var,
    ).fit(x_smooth_t, H_samples[i])
    for i in range(H_samples.shape[0])
]

Each element of ensemble is a fitted HamiltonianApproximator corresponding to one posterior sample of H. The ensemble as a whole represents uncertainty in the Hamiltonian.

To compute the mean and uncertainty of ∇H* across the ensemble:

grad_H_stack = torch.stack(
    [h.gradient(x_smooth_t) for h in ensemble]
)

grad_H_mean = grad_H_stack.mean(0)   # (T, nx)
grad_H_std = grad_H_stack.std(0)     # (T, nx)

PHSODE

Module: neuromancer.dynamics.ode | Base class: ODESystem

PHSODE simulates Port-Hamiltonian trajectories using the learned PHS matrices and a fitted HamiltonianApproximator ensemble. It integrates

ẋ = (J(x) - R(x)) · ∇H*(x) + G(x) · u

When an ensemble of approximators is passed, one trajectory is simulated per sample, giving a distribution over trajectories that reflects uncertainty in the learned Hamiltonian.

Constructor

PHSODE(
    phs_matrices: PHSMatrices,
    hamiltonian: HamiltonianApproximator | List[HamiltonianApproximator],
    nx: int,
    nu: int,
    method: str = 'dopri5',
)

Parameters

Parameter	Type	Description
`phs_matrices`	`PHSMatrices`	Trained structural matrices. Provides `J(x)`, `R(x)`, and `G(x)` during integration.
`hamiltonian`	`HamiltonianApproximator` or `List`	Single approximator or ensemble. If a list is supplied, one trajectory is simulated per approximator.
`nx`	`int`	State dimension.
`nu`	`int`	Control input dimension.
`method`	`str`	ODE solver. `'dopri5'` (adaptive RK45, default), `'rk4'` (fixed-step RK4), or `'euler'`.

Methods

simulate(
    x0: Tensor,
    t_span: Tuple[float, float],
    u: Tensor | Callable,
    dt: float = 0.01,
    t_eval: Tensor = None,
) -> Dict

Simulates PHS trajectories over a time horizon. If an ensemble was passed to the constructor, one trajectory is generated per Hamiltonian approximator and the full trajectory distribution is returned.

Parameters

Parameter	Type	Description
`x0`	`Tensor (batch, nx)`	Initial state. The batch dimension allows multiple initial conditions.
`t_span`	`(t0, tf)`	Start and end time.
`u`	see below	Control input.
`dt`	`float`	Time step used to construct `t_eval` if not provided.
`t_eval`	`Tensor (T,)`	Specific evaluation times. If `None`, generated from `t_span` and `dt`.

Control Input Modes

u supports three forms:

Form	Shape	Description
Constant	`(batch, nu)`	Same control input at every integration step.
Time-varying	`(T, batch, nu)`	One control value per time step, aligned with `t_eval`.
Feedback	`Callable(x, t) -> (batch, nu)`	Evaluated at every integration step using the current state and time.

Returns

Returns a dictionary with the following keys:

Key	Shape	Description
`'mean'`	`(T, batch, nx)`	Mean trajectory over the ensemble.
`'std'`	`(T, batch, nx)`	Standard deviation over the ensemble. Zero if a single approximator is used.
`'samples'`	`(S, T, batch, nx)`	Individual simulated trajectories, where `S` is the ensemble size.
`'t_eval'`	`(T,)`	Evaluation time points.

Usage

from neuromancer.dynamics import ode
import torch
import numpy as np

dt = 0.01
T_SIM = 25.0

# Time-varying control input: (T, batch=1, nu=1)
u_sim = torch.zeros(
    len(np.arange(0.0, T_SIM + dt, dt)),
    1,
    NU,
    dtype=torch.float32,
)

# Build PHSODE with the posterior ensemble
phsode = ode.PHSODE(
    phs,
    ensemble,
    NX,
    NU,
    method='rk4',
)

with torch.no_grad():
    result = phsode.simulate(
        x0=torch.tensor([[5.0, 0.0]], dtype=torch.float32),
        t_span=(0.0, T_SIM),
        u=u_sim,
        dt=dt,
    )

# Extract results — squeeze batch dimension
t_gp = result['t_eval'].numpy()
mean = result['mean'][:, 0, :].numpy()
std = result['std'][:, 0, :].numpy()

The [:, 0, :] indexing removes the batch dimension when simulating a single initial condition.

Notes

The batch dimension allows multiple initial conditions. Pass x0 with shape (B, nx) to simulate B trajectories simultaneously. The time-varying control input should then have shape (T, B, nu).

All integration runs inside ``torch.no_grad()``. Gradients are not needed for trajectory simulation, and disabling them reduces memory usage significantly for large ensembles.

Visualization

The neuromancer.psl.plot module provides convenience functions for visualizing the GP-PHS workflow and simulation results.

GP smoothing

Plots noisy and smoothed state trajectories together with the estimated state derivatives and their uncertainty.

plot.pltGPSmooth(
    t_all,
    trajs,
    smoothed,
    xdots,
    xdot_vars,
    x_trues=trajs_true,
)

Hamiltonian posterior

Plots the learned Hamiltonian posterior mean with ±2σ uncertainty bands and, optionally, the true Hamiltonian.

plot.pltHamiltonian(
    H_mean.numpy(),
    H_var.numpy(),
    H_true=H_true_all,
)

Derivative prediction

Plots learned state derivatives against reference derivatives with optional uncertainty bands.

plot.pltXdot(
    xdot_pred,
    xdot_true,
    xdot_std=xdot_pred_std,
)

Trajectory rollout

Plots simulated GP-PHS trajectories with optional uncertainty bands and reference trajectories.

plot.pltTrajectory(
    t_gp,
    mean,
    std=std,
    x_true=traj_true,
)

Gaussian Process Port-Hamiltonian Systems

Tutorials

Data Preparation

gp_smooth

Parameters

Returns

Usage

get_gpphs_dataloaders

Parameters

Returns

Validation

Usage

PHSMatrices

Constructor

Parameters

Structural Constraints

Parameter Auto-Detection

Methods

Validation and Warnings

Usage Example

Parameter Utilities

Usage

PHSKernel

Constructor

Parameters

Learnable Parameters

Methods

Parameters

_rbf_and_hessian(x1, x2)

Returns

Numerical Stability

PHSMeanFunction

Constructor

Parameters

Methods

Parameters

Returns

GPPHSModel

Why Not ExactGP

Constructor

Parameters

Methods

Parameters

Returns

Usage

GPPosterior

Constructor

Parameters

Methods

Parameters

Returns

forward(train_x, train_u, train_xdot, test_x, n_samples, xdot_var)

Returns

Usage

Notes

GPPHSNode

Constructor

Parameters

Owned Parameters

Methods

Parameters

Returns

posterior()

Returns

Usage

Notes

GPPHSLoss

Constructor

Methods

Parameters

Returns

Notes

HamiltonianApproximator

Constructor

Parameters

Methods

Parameters

Returns

Usage

PHSODE

Why Not `ExactGP`
